Tektronix THDP0100 User Manual

Specifications
Typical Characteristics
Typical characteristics describe typical but not guaranteed performance.
Table 6: Typical electrical characteristics
Characteristics
THDP0100 THDP0200 TMDP0200
Maximum m easurable
differential voltage
1
600 V Range:
600 V DC + peak A C
450 V
rms
150 V Range:
150 V DC + peak AC
100 V
rms
75 V Range:
75 V DC + peak AC
50 V
rms
6000 V Range:
6000 V DC + peak AC
3000 V
rms
1500 V Range:
1500 V D C + peak AC
1000 V
rms
750 V Range:
750 V DC + peak AC
500 V
rms
Maximum common mode voltage
and input voltage-to-earth
2
±6000 V DC + peak AC
2300 V CAT I
1000 V CAT III
±1500 V DC + peak AC
1000 V CAT II
600 V CAT III
±750 V DC + peak AC
550 V CAT I
300 V CAT III
CAT I Maximum Rated Over-
Voltage Transient (OVT)
3
4600 V
pk
NA 3220 V
pk
1
This is t
he maximum measurable range of the probe. Beyond these limits, the output could be clipped.
2
The Common Mode ratings are the same as the input voltage-to-earth ratings (the maximum amount that each input lead (+/-) can be from ground).
3
Applies to CAT I ratings only (both ranges). The O VT peak is typically measured on top of the Peak Working Voltage.
27 THDP0100/0200 & TMDP0200 High Voltage Differential Probes Instruction Manual
