Adjustments
Adjustment Procedures
WARNING. These procedures require the application of high voltage to the inputs of the probes. Only qualified personnel
should perfor
m any testing with voltage levels exceeding 30 V
rms
. All pertinent safety rules and guidelines for elevated
voltage measurements should be followed and adhered to.
Test Setup
1. Turn on the oscilloscope.
2. Connect the probe to any channel of the oscilloscope.
3. Verify that the LEDs light on the probe.
4. Turn on the remaining test equipment and let the probe and equipment warm up for 20 minutes.
THDP0100/0200 & TMDP 0200 High Voltage Differential P robes Instruction Manual 42
