Tektronix THDP0100 User Manual

Specifications
Specification
s
The specifications shown apply to the THDP/TMDP series probes installed o n Tektronix MSO/DSO4000 oscilloscopes.
When a probe is used with another oscilloscope, the oscilloscope must have an input impedance of 1 MΩ and a bandwidth
equal to or greater than the probe. The probe must have a warm-up period of at least 20 minutes and be in an environment
that does not exceed the limits described. (See Table 5.) Specifications for the THDP/TMDP series probes fall into three
categories: warranted, typical and nominal characteristics.
Warranted Specifications
Warranted S
pecifications
Warranted characteristics describe guaranteed performance within tolerance limits or certain type-tested requirements.
(See Table 5.)
Table 4: Warranted electrical specifications
Characteristics
THDP0100 THDP0200 TMDP0200
Rise time
1
(small signal, 10–90%,
+20 °C to +30 °C)
600 V: ≤3.6 ns
(typical: ≤3.5 ns)
6000 V: ≤3.6 ns
(typical: ≤3.5 ns)
(slew rate ≥2500 V/ns
(6000 V))
150 V: ≤2.4 ns
(typical: ≤2.2 ns)
1500 V: ≤2.0 ns
(typical: ≤1.8 ns)
(slew rate ≥650 V/ns
(1500 V))
75 V: ≤2.4 ns
(typical: ≤2.2 ns)
750 V: ≤2.0 ns
(typical: ≤1.8 ns)
(slew rate ≥275 V/ns
(750 V))
Gain accuracy ±2% ±2% ±2%
1
Output
may be slew rate limited for large amplitude signals.
Table 5: Warranted environmental specifications
Chara
cteristics
THDP0100 THDP0200 TMDP0200
Temperature
Opera
ting
Nonoperating
0°Ct
o 40 °C (32 °F to +104 °F)
–30° C to +70° C (–22 °F to +158 °F)
Humi
dity
Operating
5 to 85% RH (Relative Humidity) 0 °C to +40 °C (32 °F to +104 °F)
Non
operating
5% to 85% RH at up to +40° C (+104 °F)
5% to 45% RH above +40° C up to +70° C (+104 to +158 °F)
Altitude
Operating 3,000 m (9,842 ft)
No
noperating
15,240 m (50,000 ft)
THDP0100/0200 & TMDP 0200 High Voltage Differential P robes Instruction Manual 26
