Use the following procedures to verify the w arranted specifications of the probes. Before beginning these procedures,
photocopy the test record and use it to record the performance test results. (See Table 13 on page 38.) The recommended
calibration interval is one year.
These procedures test the following specifications:
Gain accuracy
Rise time
Required Equipment
The equipm
ent required to perform the performance verification procedures are shown in the table below. The types and
quantities of connectors may vary depending on the specific equipment you use.
Table 10: E
quipment required
Descript
ion
Minimum r
equirements
Example p
roduct
Oscillos
cope
500 MHz
Tektroni
x MSO/DSO4000
Generat
or
±100V variable amplitude, 100 Hz square wave,
calibra
ted
Fluke 9100
Pulse generator ≥50 V, 200 ns pulse width, ≤500 ps rise time, 1 kHz Avtech AVR-E2-B-W-P
Probe calibration fixture TekVPI input (See Figure 12.)
Tektronix part number 067-1701-xx
Digital Multimeter (DMM) 100 mV and 1 V true RMS AC r anges, <±0.3 %
accura
cy
Tektronix DMM4040/4050
Cable Coax,
BNC, 50Ω,36in
Tektronix part number 012-0482-xx
Adapter
BNC fe
male-to-SMA male
Tektronix part number 015-1018-xx
Adapter
BNC f
emale-to-dual banana female
Tektronix part number 103-0090-xx
Adapter
BNC
female-to-female
Tektronix part number 103-0028-xx
Adapter
BNC
male-to-dual banana male
Fluke PM9081
Termination
BN
C feedthrough, 50Ω
Tektronix part number 011-0049-xx
Attenuator
BN
C, 50Ω,2X
Tektronix part number 011-0069-xx
P
robe hook tips (2)
Included with probe accessory kit
T
ektronix part number AC280–FL
33 THDP0100/0200 & TMDP0200 High Voltage Differential Probes Instruction Manual
