Adjustments
Equipment Required
The equipment required to perform the adjustment procedures are shown in the table below. The types and quantities of
connectors may vary depending on the specific equipment you use.
Table 15: Equipment required for adjustments
Description Minimum requirements Example product
Oscilloscope
500 MHz
Tektronix MSO /DSO 4000
Generator
±100 V variable, 100 Hz square w ave, calibrated Fluke 9100
Probe calibration fixture
TekVPI inputs Tektronix part number 067-1701-xx
Digital Multimeter (DMM) 100 mV and 1 V true RMS AC r anges, <±0.3 %
accuracy
Tektronix DMM4040/4050
Cable Coax, BNC, 50 Ω,36in
Tektronix part number 012-0482-xx
Adapter
BNC female-to-SMA male
Tektronix part number 015-1018-xx
Adapter
BNC m ale-to-dual binding post
Tektronix part number 103-0035-xx
Adapter
BNC male-to-dual banana male
Fluke PM9081
Probe hook tips (2)
Included with probe accessory kit
Tektronix part number AC280–FL
Adjustment tool
Insulated, slotted (straight) head
Tektronix part number 003-1433-xx
Adjustment tool
1
Insulated, narrow-slotted (straight) head
Tektronix part number 003-1928-xx
Replacement rear-panel
label
23
Reusable, adhesive-backed label that covers
adjustment access openings
Tektronix part number 335-2913-xx
1
Requ
ired for the CMRR adjustment
2
The original label is backed with a reusable adhesive. If the label does not sufficiently adhere to the probe, order a replacement.
3
Label removal is not required to access offset zero adjustments
41 THDP0100/0200 & TMDP0200 High Voltage Differential Probes Instruction Manual
