Appendix A: TPS2000B Specications
Table 2: Input Specications (cont.)
Characteristics Description
Greater than 1000:1, up to 50 MHz, derated to 400:1 a t 200 MHz, sinewave, with Volts/Div setting
at 5 mV
Channel Common Mode
Rejection, typical
With the signal applied between the channel (signal and signal reference) to chassis, the ratio of the
acquired signal amplitude to the amplitude of the signal
TPS2012B and TPS2014B TPS2024B
100:1 at 50 MHz 100:1 at 100 MHz
Channel-to-Channel Crosstalk
Measured on one channel, with test signal applied between signal and reference of the other
channel, and with the same Scale and coupling settings on each channel
1
The maxi
mum peak-to-peak voltage that can be displayed is 40 V
P-P
with a 1X attenuation. The Vertical specications include available volts/div and probe
attenuation settings. (See Table 3.)
Table 3: Vertical Specications
Characteristics Description
Digitizers
8-bit resolution (except when set to 2 mV/div), each channel sampled simultaneously
Vertical Scale (Volts/Div)
Range
2 mV/div to 5 V/div at input BNC
Position Range
2mV/
div to 200 mV/div, ±1.8 V
> 200 mV/div to 5 V/div, ±45 V
TPP
0101 and TPP0201 Probe
Attenuation
10X
Supported Voltage Probe
Attenuation Factors
1X,
10X, 20X, 50X, 100X, 500X, 1000X
Supported Current Probe
Sc
ales
5 V/A, 1 V/A, 200 mV/A, 100 mV/A, 50 mV/A, 20 mV/A, 10 mV/A, 1 mV/A
T
PS2012B and TPS2014B
T
PS2024B
100 MHz
1
2
00 MHz
1
from 0 °C to +40 °C (+32 °F to +104 °F)
180 MHz from +40 °C to +50 °C (+ 104°F to +122 °F)
A
nalog Bandwidth in Sample
and Average modes at
BNC or w ith TPP0101 or
T
PP0201 series 10X probe,
DC Coupled
20 MHz (when vertical scale is set to < 5 mV)
75 MHz
1
Analog Bandwidth in Peak
Detect m ode (50 s/div to
5ms/div
2
), typical
20 MHz (when vertical scale is set to < 5 mV)
Selectable Analog Bandwidth
Limit, typical
20 MHz
Lower Frequency Limit, AC
Coupled
10 Hz at BNC
1 Hz when using a 10X passive probe
TPS2012B and TPS2014B TPS2024BRise Time at BNC, typical
< 3.5 ns < 2.1 ns
Peak Detect Response
2
Captures 50% or greater amplitude of pulses 12 ns wide typical (50 s/div to 5 μs/div) in the
center 8 v ertical divisions
124 TPS2000B Series Digital Oscilloscope User Manual
