Field Description
Interface Select the interface for which NAT is to be configured.
Possible values:
• -& (default value): NAT is configured for all interfaces.
• A!" B: Select one of the interfaces from the
list.
Type of traffic
Select the type of data traffic for which NAT is to be configured.
Possible values:
• " .# '-( (default value): The data
traffic that comes from outside.
• 3 *3" '-(: Outgoing data traffic.
• <",3 83 '-(: Data traffic excluded from
NAT.
NAT method
Only for Type of traffic = 3 *3" '-(
Select the NAT method for outgoing data traffic. The starting
point for choosing the NAT method is a NAT scenario in which
an "internal" source host has initiated an IP connection to an "ex-
ternal" destination host over the NAT interface, and in which an
internally valid source address and internally valid source port
are translated to an externally valid source address and an ex-
ternally valid source port.
Possible values:
• !3,," (UDP only): Any given external host may send IP
packets via the external address and the external port to the
initiating source address and the initial source port.
• #"" (UDP only): Like full-cone NAT; as ex-
ternal host, however, only the initial "external" destination host
is allowed.
• )#"" (UDP only): Like restricted-cone
NAT; however, exclusively data from the initial destination
port are allowed.
• #&" (default value) any protocol: Outbound, an ex-
ternally valid source address and an externally valid source
port are administratively set. Inbound, only response packets
14 Networking Teldat GmbH
200 bintec Rxxx2/RTxxx2
