B – Options
DPN 402196 Issue 4.1 © Teledyne TSS B- 9
Connect the SDC to the umbilical cable:
8. Refer either to section 4.2.2 "Communication Link SEP to SDC" on page 4-8 of this Manual or
to the 350 / 350 Powertrack Manual for instructions to complete the connection using the
selected communication method.
B.1.6.1 System Configuration
The DeepView for Windows software allows you to configure and control both Systems in a Dualtrack
installation.
NOTE
If you are installing Dualtrack operation as an upgrade to an existing 440, 350 or
350 Powertrack System:
❐ Ensure your SDC is capable of running Microsoft Windows™ 7 and the
DeepView for Windows software. Contact Teledyne TSS for advice if neces-
sary.
❐ In a Dualtrack System, the 440 SEP must communicate using RS232. If your
440 SEP uses 2-wire or 4-wire communications, refer to section 4.2.2.1
"Alternative Communication Methods" on page 4-11 of this Manual and set
RS232 communications before you install the SEP on the ROV.
❐ Follow the instructions in section 5.1 "Software Installation" on page 5-1 of
this Manual to install the software onto your SDC.
To configure the Dualtrack System properly you must complete the following actions.
1. Use the DeepView for Windows System Configuration Wizard to configure the 440 and the
350 or 350 Powertrack Systems correctly. Select Dualtrack for the SEP type. Refer to section
5.3 "DeepView For Windows - System Configuration" on page 5-4 of this Manual for instruc-
tions to configure the 440 System. Refer to the 350 / 350 Powertrack Manual for instructions to
configure that System.
IMPORTANT
You must select Dualtrack as the SEP type even if you intend to use only one of
the Systems during the survey.
2. Take care to enter all details completely and correctly. Set appropriate altimeter offsets for the
440 and the 350 / 350 Powertrack Systems.
B.1.6.2 System Operation
When supplied as part of a complete Dualtrack System the SDC will have all the software necessary to
operate already installed and tested. After power-on the SDC will perform an initialisation sequence
and DeepView for Windows will then start automatically.
