4.3 S-Registers for Module Setup
S0A – Main Function
Description
Defines the behaviour of the Device.
Operations
R/W LOCAL
R/W REMOTE
Becomes effective
When joining or establishing a PAN (bits F-D)
When PWM is next enabled (bit C)
Instantly (bits B-0)
Write operation
ATS0A=XXXX:<Password>
ATREMS:<address>,0A=XXXX:<Password>
Notes
For security reasons this register is password
protected. The default password for R3xx is
“password”.
See section 12 regarding secure networks
To block joining, set either bit 5 on the trust
centre or bit 0 on every node. Built-in function
0017 only overrides bit 0
An End Device (not Sleepy or Mobile) is
primarily to let a ZigBee PRO device join a
ZigBee 2006 PAN. An SED or MED is the more
usual choice
Storage
Non-Volatile
Parameters
XXXX
Where XXXX represents a 16-bit hexadecimal
number.
Range
0000 to FFFF
Bit E-F: Device Selection
Bit F
Bit E
Device Type
0
0
Router (FFD)
1
0
End Device
0
1
Sleepy End Device
1
1
Mobile End Device
Bit D: Set: If a router, do not route any
messages
Bit C: Prescale PWM clock to reduce frequency
by 256
Bit B: Set: Allows Endpoint 2 to reply to ZDO
endpoint queries
Bit A: Set: When joining don’t ask for Trust
Centre link key
Bit 9: Set: Don’t use central Trust Centre
(distributed TC Mode)
Bit 8: Set: Use Pre-Configured Trust Centre
Link Key when joining
Bit 7: Set: Trust centre uses hashed link key
Bit 6: Set: Append RSSI and LQI to all RX:
prompts
Bit 5: Set: Don’t allow nodes to join (TC setting)
Bit 4: Set: Send Network key encrypted with
the link key to nodes joining
Bit 3: Set: Do not allow nodes to re-join
unsecured
Bit 2: Set: Send Network key encrypted with
the link key to nodes re-joining unsecured
Bit 1: Set: Disable received interpan messages
Bit 0: Set: Do not allow other nodes to join the
network via this node
Factory Default
0000
SW release
R301 ●
