4 S-Registers
Most S-Registers of the ETRX357 can be read and written locally as well as remotely. The S-
Registers are summarised in the table below.
S-Register Overview
Local R/W
Remote R/W
S00
Channel Mask
(/)
(/)
S01
Transmit Power Level
(/)
(/)
S02
Preferred PAN ID
(/)
(/)
S03
Preferred Extended PAN ID
(/)
(/)
S04
Local EUI
(/-)
(/-)
S05
Local Network address
(/-)
(/-)
S06
Parent’s EUI
(/-)
(/-)
S07
Parent’s Network address
(/-)
(/-)
S08
Network Key
1
(-/)
(-/)
S09
Link Key
1
(-/)
(-/)
S0A
Main Function
1
(/)
(/)
S0B
User Readable Name
1
(/)
(/)
S0C
Password
1
(/)
(/)
S0D
Device Information
(/-)
(/-)
S0E
Prompt Enable 1
(/)
(/)
S0F
Prompt Enable 2
(/)
(/)
S10
Extended Function
(/)
(/)
S11
Device Specific
(/)
(/)
S12
UART Setup
(/)
(/)
S13
Pull-up enable
(/)
(/)
S14
Pull-down enable
(/)
(/)
S15
I/O Configuration
(/)
(/)
S16
Data Direction of I/O Port (volatile)
(/)
(/)
S17
Initial Value of S16
(/)
(/)
S18
Output Buffer of I/O Port (volatile)
(/)
(/)
S19
Initial Value of S18
(/)
(/)
S1A
Input Buffer of I/O Port (volatile)
(/-)
(/-)
S1B
Special Function pin 1 (volatile)
(/)
(/)
S1C
Initial Value of S1B
(/)
(/)
S1D
Special Function Pin 2 (volatile)
(/)
(/)
S1E
Initial Value of S1D
(/)
(/)
S1F
ADC0
(/-)
(/-)
S20
ADC1
(/-)
(/-)
S21
ADC2
(/-)
(/-)
S22
ADC3
(/-)
(/-)
S23
Immediate functionality at IRQ0
(/)
(/)
S24
Immediate functionality at IRQ1
(/)
(/)
S25
Immediate functionality at IRQ2
(/)
(/)
S26
Immediate functionality at IRQ3
(/)
(/)
1
Password Protected Registers
