Defines the behaviour of the Device.
Operations
R/W LOCAL
R/W REMOTE
Becomes effective
Instantly
Note
On the ETRX3 series IRQ0,1,2,3 are generated
by logic transitions on inputs PA0, PA1, PB0 and
PB6 respectively
If bit 8 is not set, the shortest interrupt pulse is
450ns.
Storage
Non-Volatile
XXXX
Where XXXX represents a 16-bit hexadecimal
number.
Bit F (MSB): Set: PB7 is PWM as defined by
S1B/S1D.
Unset: Standard I/O pin.
Bit E: Set: Enable Boost Mode
Bit D: Set: Show POLLED: prompt
Bit C: Reserved
Bit B: Reserved
Bit A: Reserved
Bit 9: Set: Enable wakeup on UART activity
(1st input character is discarded)
Bit 8: Set: Enable 100ms debouncing for all
IRQs
Bit 7: Set: IRQ3 on rising edge
Bit 6: Set: IRQ3 on falling edge
Bit 5: Set: IRQ2 on rising edge
Bit 4: Set: IRQ2 on falling edge
Bit 3: Set: IRQ1 on rising edge
Bit 2: Set: IRQ1 on falling edge
Bit 1: Set: IRQ0 on rising edge
Bit 0: Set: IRQ0 on falling edge
Factory Default
0005
