2.2 Prompt Overview
The following prompts can show up during the operation of the ETRX357 modules. Most of the
prompts can be disabled using register S0E and S0F.
Prompt Overview
OK
OK terminator
ERROR:XX
Error number XX occurred
ACK:XX
Acknowledgement for message XX was received
NACK:XX
Acknowledgement for message XX was not
received
POLLED:XX
Shown on an end device when it polls its parent
and S11 bit D is set. XX codes are:
00 - Success
31 - no data pending on host
66 - poll could not be executed
40 - no ack from parent
SR:XX,<EUI64>,<NWK addr>,…
Route Record Message received
BCAST:[<EUI64>,]XX=<data>
[,<RSSI>,<LQI>]
A Broadcast with XX characters has been
received
MCAST:[<EUI64>,]XX=<data>
[,<RSSI>,<LQI>]
A Multicast with XX characters has been received
UCAST:[<EUI64>,]XX=<data>
[,<RSSI>,<LQI>]
A Unicast with XX characters has been received
INTERPAN:<ProfileID>,<ClusterID>,
<Msgtype>,<Option>,[GroupID],<PanID>,
<SrcAddr>,<MsgLength>,<Msg>
The device has received an interpan message
<ProfileID> - 16 bit hex
<ClusterID> - 16 bit hex
<Msgtype> - 8 bit hex
0x00 – Unicast
0x08 – Broadcast
0x0C- Multicast
<Option> - 16 bit hex. If it is 0x0002 the
<SrcAddr> will be source long address, and
otherwise it is source network address
[GroupID] – 16 bit hex, shown if the message is
sent to a group
<PanID> - 16 bit hex, source PAN ID
<SrcAddr> - 16 bit hex source node ID or EUI
<MsgLength> - 8 bit hex, message length
<Msg> - received message in hex format
RAW:snn,<data>
A raw message has been received with strength
snn dBm
SDATA:[<EUI64>,],<ioread>,<ADC0>,
<ADC1>,<sequenceNo>,<Vcc>
A data message has been received at the sink.
ADC data is ADC0 & ADC1
