Defines the behaviour of the Device.
Operations
R/W LOCAL
R/W REMOTE
Becomes effective
Instantly
Notes
Bit C: the ETRX357-LRS and ETRX357HR-LRS
have an RF preamplifier, so the reported RSSI is
12dB higher than the power at the antenna
Do not set bit 8 if the sink is likely to be missing
and transmissions to the sink are frequent
(about once a second)!
Storage
Non-Volatile
Parameters
XXXX
Where XXXX represents a 16-bit hexadecimal
number.
Range
0000 to FFFF
Bit F: Set: Don’t exit data mode in case of data
loss
Bit E: Set: Don’t accept Data Mode
Bit D: Set: High RAM concentrator instead of
Low RAM concentrator
Bit C: Set: Display RSSI and LQI of the last hop
when devices report to AT+SN or
AT+ANNCE
Bit B: Set: UCASTs and SCASTs wait for ACK
Bit A: Set: Disable playing Tune when receiving
AT+IDENT
Bit 9: Set: Enable one second character
timeout when entering data for xCASTB
Bit 8: Set: Actively search for a sink if none is
known
Bit 7: Set: Node doesn’t replace existing sink
with better one (lower cost)
Bit 6: Set: Node doesn’t lose sink if it couldn’t
be reached for three times
Bit 5: Set: Sink won’t reply to nodes searching
for a sink
Bit 4: Set: Node is Sink
Bit 3: Set: Changes to S01 take effect instantly
Bit 2: Set: Send BCAST[B] messages to
routers only
Bit 1: Set: Send unicast messages
unacknowledged
Bit 0: Set: Don’t attach EUI64 to NWK frame
when sending a message.
Factory Default
0000
