40 • 4. Remote Configuration
MCC201/MCC201H User manual
FTP Upload
Specify the information to upload event information, when FTP is selected as an event action.
Server Address: Enter an address of an FTP server to receive video files.
Port: Specify a port for FTP operation (Port 21 is the default port in FTP operation. If a different port
is configured in the FTP server, this port needs to be changed accordingly).
ID & password: Enter ID and Password for accessing the FTP server.
FTP File name: The names of files upload by FTP can be specified by user. If a fixed name is specified,
the file is overwritten repeatedly.
Max length of a file name is 60 characters. If the name is left blank, file name is determined according to
the internal rule implemented in the firmware.
The following macros are supported to form variable parts of file names. The strings are case-sensitive.
%YYYY : year
%MM : month
%DD : day
%hh : hour
%mm : minute
%ss : second
%EVENT : event type (Sensor1, Motion, ...)
%ADDR : address of the server (Domain name when DDNS is used.
Otherwise IPaddress)
“.avi” or “.jpg” will be added automatically at the end of the filename depending on the type of video file.
FTP Base Directory: Specify the name of the directory to be created in the FTP server. It is valid only
when Use Record is set to Use FTP on Record session.
Upload video: Primary Video and Secondary Video (H.264 only), JPEG Capture can be selected for
uploading. The duration of video clip can be configured with Pre-Event Time and Post-Event Time in
Event Record section.
Number of Frame: Enter frame number of JPEG Capture (from 1 to 10).
