LCD64 - Operation Manual 5
English
Description
The LCD64 keyboard provides complete control and status of the CA62 control
panel.
The control panel can be fully programmed from the LCD64 keypad.
The alarm events and system status are visualized by an LED indication and icon
LCD display. A sound buzzer informs the user about correct and incorrect key entries
as well as activated alerts.
LED Indication
LED Light Blinking
READY (green) System ready Programming mode
ARM (red) System armed Exit time / Programming mode
TRBL (yellow) - Technical problem / Programming mode
Keypad Sounder
There are 7 different sound combinations that indicate seven different conditions:
 - single short beep indicating button pressing.
  - two long beeps, indicating the system conrmation to executed
operation (arming, disarming, settings change, etc.).
 - single long beep, indicating incorrectly executed operation.
 - continuous beep, indicating intrusion into the entrance zones.
 - short beeps, indicating the system is armed and the user is required
to leave the area. 10 seconds before the exit time is over, beeps frequency is in-
creased.
 - two short beeps at every 20 sec, indicating a technical trouble
(battery low, no supply voltage, etc.). To stop the signalization press sequentially the
buttons
→ .
 - short beeps with subsequently increasing period indicating intrusion into
a zone with a “Chime“ option activated.
Display
An icon LCD display provides information for the status of the Partitions (A and
B) in the system, and also the type of ARMING mode - “Full ARM” (see page 9),
“Stay ARM” (see page 9) and “Instant ARM” (see page 10). The LCD64 keyboard
is equipped with blue backlight of the buttons and LCD display. The backlight is
activated easily with pressing a random button, opening of “Entry-Exit” or “Follow”
type zones.
