Data over Coax Gateway Ref.769301
45
Specifications
WiFi Interface
• WiFi 802.11bgn with 2x2 MIMO.
• Maximum througput 144Mbps for a 20MHz Channel
and 300Mbps for a 40MHz channel within 802.11n
• WiFi power selection by means of a front pannel
switch. Three positions, NORMAL, LOW POWER,
OFF.
• Maximum transmission power 17dBm in normal
mode. 3 dBm in low power mode.
• WPS Button (Wireless protected setup) for ease of
connection.
• WiFi Security WEP, WPA/WPA2 & 802.1x
Coaxial/PLC Interface
• Coaxial/PLC to ethernet adapter.
• Supports HomeNetworking and MDU/MTU modes.
• Up to 253 devices per Master in MDU/MTU mode.
• Protocol supports up to 4 Masters sharing the same
return path band with up 1012 devices.
• Frequency range : 2-67,5MHz
• TV Frequency range: 87-2150MHz
• Maximum attenuation: 85 dB
• Output Level: 130 dbµV
• Spectrum power density: –50dBm/Hz
• Minimum spectral power density: -135dBm/Hz
• Temperature range: -5ºC a 45ºC
Coverage
• Coaxial Cable: 1.2Km
• PowerLine: 300 m
Information LED’s
• Power LED: Power, active, booting & firmware error.
• Internet LED: Access to the Internet. Bridge
mode.No network .
• WiFi LED: Normal Power, Low Power, OFF.
• Medium LED: Coax/Hybrid(Coax-PLC)
• Link LED: Link & activity indicator on Coax-PLC
• 100/10Mbps: Link & activity indicator on Ethernet
Modulation & Channel coding
• Wi-Fi DSSS (IEEE 802.11b) Wi-Fi OFDM (IEEE
802.11 g, n)
• Dynamic channel adaptation to transmission
conditions both in the coax & PLC medium.
Syncrhronization to power as condiciones del canal
coaxial y frequency 50/60 Hz.
• OFDM 2880 carriers, QAM 4096/1024/256/
64/16/8, QPSK, BPSK & ROBO mode.
• FEC (forward error correction) & TCC (Turbo
Convolutional Codes) error recovery.
Range
• Coax Cable: 1.2Km
• PowerLine: 300 m
Quality of Service QoS
• Multicast. IGMP snooping. MLDv2/IGMPv3/ IGMPv2.
• Four priorization queues.
• VLAN IEEE 802.1p based priorization
• Type of service (ToS) & Cos (Class of Service)
• Classification based on origin / destination MAC.
• Classification based on origin / destination Ip
address.
• More filters / classification protocols.
Power supply
• 108V-254V~ 50/60Hz
• Power consmuption: 6 Watts Max
Working modes
• HomeNetworking: Asyncronous mode based on
low lattency CSMA/CA.
• MxU: Syncronous mode token based (Hidden Node)
syncronizing slaves and supporting long range.
Security
• WiFi authentification including WEP, WPA/WPA2 y
802.1x.
• Private network security based on NPW (Network
Password key).
• AES-128 Encryption (NEK, Network Encrytion key).
• Configuration protection by means of NVAK (Non-
Volatile Access key).
Connectors
• EURO Power jack
• 2 x “F” 75 Ohm connectors. Low pass filter for DATA
(2-67,5Mhz) & high pass filter for TV services.
(87Mhz-2150Mhz).
• 3 x RJ45 Ethernet 100/10Mbps.Auto MDI/MDIX.
Norms
• EN 60950-1:2007/AC:2012: Product safety
• EN 55022:2008 Electromagnetic interference
• EN 55024:2011 Inmunity
• EN 50412-2-1:2006 Inmunity requirements in
low power networks for power line
communications.
• EN 300 328 V1.7.1, EN 62311:2008: Radiation
norm in the 2.4 Ghz band.
