EN
21
12.2. Conguration
Press
to change LT Monitoring options.
- Measure delay: Select the time interval
between two consecutive measure shots.
Minimun value is 1 second.
- Measure 1, 2, 3: Allows select the three
measures that the user wants to visualize in
the main window:
13. Wi-Fi Scan (H30D+Adv)
Analyzes the Wi-Fi band and automatically detects
all the Wi-Fi networks, as well as their names and
the power of the access point’s signal.
There are two dierent screens to display the
information: List and Map.
11.1. List view
You can go through the list using and select
one of the Wi-Fi networks to display it separately.
If a Wi-Fi network has multiple access points, you
will see several networks with the same name. If
you select one of them, you will separately all the
access points of that network. The rst one in the
list is the one you are connected to, which is the
one that has more signal power at that point.
Power of each Wi-Fi
access point’s signal.
The list is sorted by
power
Wi-Fi network’s channel
Wi-Fi network’s name
The red lock indicates
that the network is
locked
Wi-Fi network’s MAC
Wi-Fi protect access type
Graph showing the wi networks. Each
triangle represents a network. The height
of the triangle represents the power of the
access point’s signal.
