Televes H30+ User Manual

H30+ H30D+ - CATV & DOCSIS 3.1 Meter /Analyzer
4
Safety requirements
Product inspection
- Inspect the equipment for shipping damage.
Should any damage be discovered, immediately
le a claim with the carrier.
Read and Follow All Instructions
- All the safety and operating instructions should
be read prior to and followed while operating
this product.
Cleaning
- Follow the cleaning instructions contained in
the Maintenance section of this manual.
Attachments
- Do not use attachments that are not approved
by the product manufacturer.
Water and Moisture
- This product is weather resistant but is not
submersible.
Power Sources
- This product should be operated only from the
type of power source specied.
Grounding or Polarization
- Do not bypass or defeat electrical plug
polarization or grounding. Doing so will violate
the warranty and may pose a risk of re or
electrocution.
Wire Protection
- Ensure all connected wiring is routed correctly
to avoid damage including pinching, excessive
bends, or compression.
Electrical Supply, Grounding, and Surge
Protection
- Ensure that all local or national electrical codes
are followed.
Power Lines
- Always use caution and avoid operating this
or any connected equipment near uninsulated
power lines or any other hazards.
Servicing
- There are no user serviceable parts except the
battery. Do not attempt to service this product or
remove covers other than the battery cover. Refer
all servicing to qualied service personnel. Follow
the instructions in this manual when replacing the
battery.
Heat
- The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including ampliers) that produce
heat.
Maximum in the power connector
- Ensure that the voltage applied to the power
connector does not exceed 15V. Higher voltages
could damage the equipment
Maximum voltage at the RF connector
- Ensure that the voltage applied to the RF connector
does not exceed +-150 VDC nor 150 VAC. Higher
voltages could damage the equipment.

Televes H30+ Specifications

General

Input Impedance	75 Ω
Power Supply	100-240 V AC, 50/60 Hz
Display	2.8-inch color LCD
Battery	Li-Ion
Connectors	F-type
Measurements	MER, BER, C/N
Battery Life	4 hours
