Televes H30+ User Manual

EN
7
Technical Specifications
References
H30+ 593980
H30D+ 593981
H30D+ Advance 593985
Frequency
Range
593980: 5 MHz to 1002 MHz
593981: 5 MHz to 1218 MHz
593985: 5 MHz to 1794 MHz
Resolution 50 kHz
Tuning Frequency or channel
Input
Impedance 75Ω F-type connector
Spectrum Analyzer
Span
2.5, 6.25, 12.5, 25, 62.5, 125, 250, 500 MHz
and Full
Scale 5 and 10 dB/div
Auto and manual
reference level
Reverse Path Ingress Scan
Range
Selectable 5 to 42MHz, 5 to 65MHz, 5 to 85MHz
and 5 to 204MHz
Mode Peak, Average, Min, and Real-time
Digital Channel Power Measurements
Power -15 to +50 dBmV (-35 to +60dBmV opt.593235)
Accuracy ±2dB
Resolution 0.1dB
Digital Measurements ATSC 1.0
Freq. Range 42 - 1002MHz
MER Up to 38dB
PreBER 9.9E-2 - 1.0E-6
PostBER 1.0E-3 - 1.0E-8
Constellation with
Zoom Capability
Digital Measurements ATSC 3.0 (H30D+Adv or opt. 593280)
Freq. Range 42 - 1002MHz
MER Up to 38dB
LDPCBER 1.0E-2 - 1.0E-6
BCHBER 1.0E-3 - 1.0E-8
Echoes
Constellation with
Zoom Capability
Digital Measurements QAM
Freq. Range 42 - 1002MHz
Demodulation ITU-T J.83 Annex A/B standard
Support 16, 32, 64, 128 and 256 QAM, QPSK
Symbol Rate 2 to 6.9 MS/sec
Q.A.L. Technology
(QAM Auto Lock)
Automatic detection of signal characteristics and
modulation parameters
C/N Up to 45 dB
MER Up to 45 dB
Pre-BER and Post-BER
(Annex B)
1.0E-3 to 1.0E-8
BER (Annex A) 1.0E-3 to 1.0E-8
Constellation with
Zoom Capability

Analog Measurements
Freq. Range 42 MHz to 1002 MHz
Level measurement -15 to +50 dBmV (-35 to +60dBmV opt.593235)
V/A up to 30 dB
C/N up to 54 dB
Accuracy ±2 dB
Resolution 0.1 dB
Channel Plans
Factory channel plans FCC STD, FCC EXT, FCC OFFAIR, CCIR, CCIR+LTE
Custom channel plans
(learning plan)

System Scan
Channels
User selectable zoom up to all channels (analog
or digital)
Measurements
Level bar representation and C/N BER/MER of the
selected channel
Tilt
Channels Up to 16 channels (analog and/or digital)
Selectable markers
Pass/Fail Indicators
Factory proles
Headend, Fiber Nod, Trunk, Bridge, Line Ext, Tap,
End Line, Ground, Modem/STB, O Air
Custom proles up to 20 proles
Voltmeter
Range ±5VDC to ±150VDC, ±5VAC to ±100VAC
Accuracy ±(0.5V +1%)
Speed Test
DCHP Status
Connection Status
Ping
Lost packets
DS/US speeds
593901: 20Mbps
593902: 500Mbps
593905: 1000Mbps
Service Info
Channel parameters NIT, PAT, TSID, CBRT, number of services
Service parameters SID, VID, AID, bitrate, encoding type
Video visualization MPEG-2 / MPEG-4
HEVC visualization Up to 1080p (H30D+Adv or opt. 593252)
Cable Modem (H30D+ / H30D+ Adv)
Modes 3.1 / 3.0 / BPI+
Dowstream
Up to 32 QAM channels and 2 OFDM channels
of 192MHz
UpStream Up to 8 QAM channels and 2 OFDM-A channels
Connect Status
DS and US frequency, DHCP, TOD, cong. le
name, security level, registration
Diplexer
Auto (cong. le) or user selectable (5-85MHz /
108-1002MHz) (5-204MHz / 258-1218MHz)
Measurements
Bar diagram of DS and US channels. Power, MER,
PreBER and PostBER of selected channel

Televes H30+ Specifications

General

Input Impedance	75 Ω
Power Supply	100-240 V AC, 50/60 Hz
Display	2.8-inch color LCD
Battery	Li-Ion
Connectors	F-type
Measurements	MER, BER, C/N
Battery Life	4 hours
