H30+ H30D+ - CATV & DOCSIS 3.1 Meter /Analyzer
26
2. Plans
In this window, you can see all the channel plans of
your H30+/D+/D+Adv.
2.1.- Terrestrial and Customer Channel Plans
The channel plans are grouped in three categories:
Terrestrial and Customer.
The default Terrestrial channel plans are the
standard channel plans.
These plans can be removed from the meter, but
they can not be edited. However, you can make
a copy of one of them to build a new customer
channel plan from it.
The duplicated plans will appear in the Customer
list automatically.
The customer channel plans can be edited:
Display channel plan Delete the plan
Duplicate the plan
Add new plan
Duplicate plan
Type in the cells
to edit the data
Add
channel
Save changes in the
plan and upload it
to the meter
Delete plan
Delete selected
channels
To change the display mode from calendar mode
to list mode, just click on the corresponding button
placed at the menu bar:
Using the buttons placed at the top right of the
screen, you can remove the selected Datalogs or
download them to your computer in .xls format
(it will be generated a .xls le for each Datalog and
they all will be downloaded together in a .zip le)
Clicking on a Datalog of the list, the measurements
of that Datalog will be displayed:
Download/
remove the
selected Datalogs
Change calendar/
list display mode
Datalogs
list
Select/unselect all
the Datalogs
Remove/export
to xls
Date of the measurement,
channel plan, and Datalog
name
Channel measurements
Filter according to channel type
