H30+ H30D+ - CATV & DOCSIS 3.1 Meter /Analyzer
10
Battery Recommendations
To maximize battery life:
Avoid fully discharging the battery.
The battery should always be charged with the
battery pack attached to the device and using
the supplied DC adapter or applying a constant
voltage within the specied range (12-15VDC).
For long term storage, keep the unit at room
temperature, or about 25º C. Start with a charged
battery and re-charge the battery every 2 to 3
months.
Product operation
1. Docsis
(H30D+ / H30D+Adv)
In this menu are grouped all functions related to
Docsis network.
1.1. Connection Status
This function shows all the steps the H30D+/
H30D+Adv is taking to connect to a DOCSIS
network.
Each time a step is successfully completed, it is
indicated with a checkmark.
The steps are shown in order.
The rst thing that the modem has to do is read the
status of the connection.
Then, the modem has to range and lock on to the
downstream channel. Once the modem is locked,
it is shown the frequency of the channel used
for receiving data from the CMTS (Cable Modem
Termination System). The modem will then
attempt the same with the upstream channel.
Then, the DHCP server must assign the IP network
parameters to the modem. The next step is to
synchronize the time with the TOD (Time Of Day)
server. In both cases, the IP addresses of the servers
will be shown in the window.
The modem then gets and displays the name of
the conguration le given by the CMTS.
Last, is the modem registration status, the level of
security (None or BPI+), the DOCSIS version, and
the channel bonding conguration.
