User manual “SCART DVB-T 7117 ”
42
Name Function
SCART TO TV Connection to the Euroconnector of the TV or VCR
Host USB Connection of the USB cable to connect a memory stick, an MP3 player or an external disk
RF IN Signal input from the terrestrial aerial
DC INPUT Connection for the power adaptor
IR Connection for the IR sensor. The sensor should be located in a visible spot
A/V OUT Audio/Video signal output to connect to other devices
3.- Description of connections
SCART TO TV
Host USB
RF IN
DC INPUT
IR
A/V OUT
