User manual
“SCART DVB-T 7117
”
73
ENGLISH
DVB-T Receiver:
Input frequencies 170...230 MHz and 470...862MHz
Input Connector CEI
Impedance 75 Ohms
Output Connector IEC
Video System PAL B/G, SECAM, NTSC
Filter 6, 7, 8 MHz
Demodulation CODFM 2k/8k
Aerial feed 5V/100mA
De-Multiplexing MPEG II, ISO/IEC 13818-1
Video Decoding:
Video compression MPEG-2 Compatible MP@ML (Main profile @ main level)
Video Standard PAL / NTSC
Image 720 pixels x 576 lines / 724 pixels x 480 lines
Format 4:3 Letterbox / 4:3 Pan Scan / 16:9 / Auto
Audio Decoding:
Compression MPEG-2 Layer I & II
Audio Mode Dual (main/sub), Stereo
Frequency sample 32KHz, 44.1KHz, 48KHz
Audio Parameters:
Analog Output:
Output level 0.5 rms (nominal)
Output impedance 600 Ohms
THD >60dB (1KHz)
Video Parameters:
Output
CVBS Output level 1 Vpp / 75 Ohms
RED Output level 0.7 Vpp / 75 Ohms
GREEN Output leve 0.7 Vpp / 75 Ohms
BLUE Output level: 0.7 Vpp / 75 Ohms
Tele-text:
Tele-text Standard ETS 300 472
SCART Connector:
Output: CVBS and RGB
USB Interface:
Type Mini USB
USB port 1.1/2.0
Mains:
Mains power: 90 - 260V~ 50/60 HZ
DVB-T powering: 12V (300mA), 5V (600mA), 3,3V (1200mA)
Power consumed: < 8 W
General:
EPG Current events, future events and those prior to the selected program
Timer 8 events, up to one year ahead of time
OSD Language English, French, German, Italian, Spanish, Swedish, Portuguese, Finnish, Dutch, Turkish, Czech, Greek
and Danish
Temperature +15 ºC....+35 ºC
Humidity <80%
Dimensions (L x W x H): 100mm x 69mm x 23,5mm
Weight: 200 grs.
Technical Features
