C-2000 and C-2000HS Technical Manual Setup 19
Bosch Security Systems, Inc. Technical Manual F.01U.174.927 Rev 03
The display shows the setup option number and no decimal points. The selection scrolls to those option values available to that
setup state, i.e., an enable/disable setup state has option 1 and 2, with 1=enable and 2=disable and no other. Now, pressing the
Enter (#) key programs the selected option for the current state. Once programming completes, the display shows
OC (Option Changed), then display the current setup state.
Saving the changes made to a setup state is done by pressing and holding IC and pressing D. The display shows
SS (Settings Saved) and then returns to the current Setup State. Exiting setup mode automatically saves the settings. If the
settings are not saved and power is lost, the changes will be discarded.
There are certain setup states with more complex user interface features. For more information about status states,
see Setup Mode on page 17.
TABLE 3. Setup States and Setup State Options
Setup State
Number
Setup State Description
0 PIN Number Entry/Idle Automatically entered when Setup Mode is accessed.
1 PIN Number Change Used to change the Setup Mode PIN number.
2 Guard/Hold Tone Frequency Selects between 2175Hz and 2300Hz.
3 Guard Tone Level Sets the level of the Guard tone.
4 Guard Tone Duration Sets the Guard tone duration
5 Hold Tone Level Sets the Hold tone level
6 Hold Tone Hang Time Sets the time PTT and the hold tone is held after the Key release.
7 Function Tone Level Sets the level of the Function Tone.
8 Function Tone Duration Sets the duration of the Function Tone.
9 Single/Dual Function Tone
Mode
10 Function Tone Frequency
Select Mode
Single mode F-Tone frequency.
11 MON Frequency Selection Set Frequency of the monitor tone. 2050Hz default.
12 DTMF Keypad Enable/
Disable
13 DTMF Tone Level Set the level of the DTMF tone generator.
14 DTMF Hang Timer Time between DTMF tones that the Guard/Hold tone will wait.
15 MIC AGC
16 RX AGC
17 Main Speaker with Handset
Enable/Disable
18 Single Frequency Telephone
Mode
a
19 Auxiliary Speaker Enable/
Disable
20 Function Tone Enable/Disable Select any F-tone from 1–99 to enable or disable, either mode.
21 Crossmute Enable/Disable
22 Minimum Speaker Audio Level
Enable/Disable
Min Speaker audio level Enable/Disable:
23 Handset Mic Gain Setting Set the gain used for input audio on the handset microphone.
24 Desk Mic Gain Setting Set the gain used for input audio on the desk microphone.
25 AUX Port Gain Setting Set the gain used for input audio on the auxiliary port.
26 Panel Mic Gain Setting
27 RX Gain Setting Set the gain for the input RX audio.
28 TX Gain Setting Set the gain for the output TX audio.
29 Clone Mode Entry Enter the Clone mode. Press enter key, then select RX or TX.
30 Duplex Mode Enable/Disable
