Exiting and saving the changes to the Function Tone Frequency setup mode can be achieved in the following manner: First,
exit the function tone frequency setup mode by pressing the Escape key (*). This takes you to the entry point for setup state 10.
From here the user navigates to any other setup state.
To save the changes, do the following:
1. Simply press and hold the IC key.
2. Press DTMF D.
Display will show SS (Saved Settings).
NOTE: In the options with a Function Number (F1-F16) and MON in the cell, indicate the default frequencies for that
Function Tone.
Function Tone setup mode overview:
FUNCTION UP (
 ) and DOWN (  ): Set the current Function Tone to be modified.
VOLUME UP/DOWN: Set the current Function Tone Frequency.
DTMF A and B: Select the main or sub Function Tone to be programmed.
TRANSMIT key: Show the current Function Tone once the display changes to the setup
option.
DTMF *: Escape out of Function Tone Frequency setup mode.
IC and D: Method used to save the changes made in Setup Mode.
TABLE 12. Available Function and Monitor frequencies.
Option Frequency Option Frequency Option Frequency
1 400Hz 19 1300Hz 37 2200Hz
2-F16 450Hz 20-F7 1350Hz 38 2250Hz
3 500Hz 21 1400Hz 39 2300Hz
4-F15 550Hz 22-F6 1450Hz 40 2350Hz
5 600Hz 23 1500Hz 41 2400Hz
6-F14 650Hz 24-F5 1550Hz 42 2450Hz
7 700Hz 25 1600Hz 43 2500Hz
8-F13 750Hz 26-F4 1650Hz 44 2550Hz
9 800Hz 27 1700Hz 45 2600Hz
10-F12 850Hz 28-F3 1750Hz 46 2650Hz
11 900Hz 29 1800Hz 47 2700Hz
12-F11 950Hz 30-F2 1850Hz 48 2750Hz
13 1000Hz 31 1900Hz 49 2800Hz
14-F10 1050Hz 32-F1 1950Hz 50 2850Hz
15 1100Hz 33 2000Hz 51 2900Hz
16-F9 1150Hz 34-MON 2050Hz 52 2950Hz
17 1200Hz 35 2100Hz 53 3000Hz
18-F8 1250Hz 36 2150Hz
