ME910G1 HW Design Guide
1VV0301593 Rev.7 Page 46 of 98 2021-02-02
Example circuit:
Figure 12: example circuit
Note
: Consider voltage drop under max current
conditions when
defining the voltage detector thereshold in order to avoid unwanted
shutdown.
The capacitor is rated with the following formula:
Tip
:
Make the same plot during system verification to check
timings and voltage levels.
Fast Shut Down by Software
The fast shut down can be triggered by AT command.
