ME910G1 HW Design Guide
1VV0301593 Rev.7 Page 69 of 98 2021-02-02
9. MECHANICAL DESIGN
Drawing
Figure 24: ME910G1 Mechanical Drawing
Dimensions in mm
PIN B1
Lead Free Alloy:
Surface Finishing Ni/Au for all solder pads
