Telit Wireless Solutions SL869-V2 Series User Manual

SL869x-V2 Family Product User Guide
1VV0301175 Rev. 9 Page 43 of 93 2021-07-15
Not Subject to NDA
9.1.6. SL869-V2S Pin-out Table
Pad
Name
Type
Description
1
NC
NC
No Connection
2
NC
NC
No Connection
3
1PPS
O
Time mark Pulse
4
NC
NC
No Connection
5
NC
NC
No Connection
6
NC
NC
No Connection
7
NC
NC
No Connection
8
NC
NC
No Connection
9
VCC_RF
PWR
Antenna (Bias-T) Supply Voltage
(connected by internal trace to pin 23)
10
GND
GND
Ground
11
RF_IN
I
GNSS RF Input, 50 Ohm (pre-select SAW filter)
12
GND
GND
Ground
13
GND
GND
Ground
14
NC
NC
No Connection
15
NC
NC
No Connection
16
NC
NC
No Connection
17
NC
NC
No Connection
18
NC
NC
No Connection
19
NC
NC
No Connection
20
TX
O
TX
21
RX
I
RX
22
VBATT
PWR
Backup Voltage Supply
23
VCC_IN
PWR
Supply Voltage (internally connected to pin 9)
24
GND
GND
Ground
Note: All GROUND pins must be connected to ground
Table 19: SL869-V2S Pin-out Table
