SL869x-V2 Family Product User Guide
1VV0301175 Rev. 9 Page 47 of 93 2021-07-15
Not Subject to NDA
Note that Vbatt is internally connected to Vcc through a diode, so it may be left
unconnected if not required by the application design. Vbatt should be lower than Vcc to
avoid current swings during operation as the battery-backed RAM is accessed.
9.2.3. VCC_RF
VCC_RF is directly connected to Vcc by an internal trace and may be used to power an
external LNA or bias-T. Maximum current available is 50 mA. It may be left unconnected.
9.2.4. DC Power Requirements
Main Supply Voltage & Backup Voltage
Supply
Name
Min
Typ
Max
Units
Vcc and Vbatt
Vcc & Vbatt
3.0
3.3
4.3
V
The drop from 3.0 V to 0 V must be > 1 ms.
Also, keep the supply ripple as low as possible (< 50 mV)
Table 21: DC Supply Voltage
9.2.5. DC Power Consumption: SL869-V2
State & Constellation
Typ
Max
Units
Acquisition
GPS Only
84
123
mW
GPS and Glonass
103
146
mW
GPS and BeiDou
94
143
mW
Navigation/Tracking
GPS Only
74
120
mW
GPS and Glonass
81
139
mW
GPS and BeiDou
92
152
mW
Low Power – Periodic (500 ms On)
GPS Only
19
mW
GPS and (Glonass or BeiDou)
25
mW
Vbatt
50
99
μW
Operating temperature: 25°C
Supply voltages: 3.3 VDC nominal
SBAS: enabled
1PPS sync: enabled
Table 22: SL869-V2 Power Consumption
