SL869x-V2 Family Product User Guide

1VV0301175 Rev. 9 Page 70 of 93 2021-07-15

Not Subject to NDA

Product Packaging

SL869-V2 modules are shipped in Tape and Reel form on 24 mm reels with 1000 units per

reel or Trays with 72 units. Each reel or tray is ‘dry’ packaged and vacuum sealed in a

Moisture Barrier Bag (MBB) with two silica gel packs and a humidity indicator card which

is then placed in a carton.

All packaging is ESD protective lined.

Figure 29: Tape and Reel Packaging
