WE310G4-I/P Module Hardware User Guide
1VV0301767 Rev. 5 Page 19 of 48 2022-11-08
Not Subject to NDA
Power Consumption Typical Average (mA)
Standby 0.003
Idle (Radio OFF, UART ON) 13.6
Deep Sleep (Radio OFF) (no Wi-Fi Association) 0.05
Deep Sleep (Radio ON) (with Wi-Fi Association) 1.74
DTIM=1 1.19
DTIM=3 0.545
DTIM=10 0.189
BLE RX (peak current, connected to BT NW) 54.5
BLE TX (peak current, connected to BT NW) 55.1
Wi-Fi RX (continuous) 53
Table 10: Module power consumption in different states
WLAN Continuous Tx power consumption
The table below shows the current consumed by the module at different WLAN data
rates. These measurements are obtained from a DC power analyzer.
Wi-Fi 2.4GHz / CH 6
Modulation Data Rates
WE310G4-I
Current
b
BPSK 1 Mbps 17 243
QPSK 2 Mbps 17 242
CCK 5.5 Mbps 17 238
CCK 11 Mbps 17 232
g
BPSK 6 Mbps 16 212
BPSK 9 Mbps 16 207
QPSK 12 Mbps 16 202
QPSK 18 Mbps 16 197
16 QAM 24 Mbps 16 192
16 QAM 36 Mbps 16 177
64 QAM 48 Mbps 16 170
64 QAM 54 Mbps 16 165
n
BPSK MCS0_20 15 202
QPSK MCS1_20 15 192
QPSK MCS2_20 15 187
16 QAM MCS3_20 15 178
16 QAM MCS4_20 15 168
64 QAM MCS5_20 15 160
64 QAM MCS6_20 15 157
64 QAM MCS7_20 15 152
BPSK MCS0_40 14 192
QPSK MCS1_40 14 182
QPSK MCS2_40 14 168
16QAM MCS3_40 14 162
16QAM MCS4_40 13 145
64QAM MCS5_40 13 137
64QUAM MCS6_40 13 133
64QAM MCS7_40 13 130
Table 11: 2G WLAN Continuous Tx 2.4GHz Power consumption
Wi-Fi 5GHz CH100
Standard 802.11x
Modulation Data Rates
WE310G4-I
RF Output (dBm)
Current
mA@3.3V
a
BPSK 6 Mbps 13 268
BPSK 9 Mbps 13 262
To Next Page
