Telit Wireless Solutions WE310G4-I - BLE Tx Power; BLE Rx Sensitivity

WE310G4-I/P Module Hardware User Guide
1VV0301767 Rev. 5 Page 22 of 48 2022-11-08
Not Subject to NDA
Wi
-
Fi 2
.
4
GHz
/ CH
6
Modulation
Data Rates
Sensitivity (
dBm)
CCK 5.5 Mbps -89
CCK 11 Mbps -89
g
BPSK 6 Mbps -92
BPSK 9 Mbps -90
QPSK 12 Mbps -88
QPSK 18 Mbps -87
16 QAM 24 Mbps -84
16 QAM 36 Mbps -80
64 QAM 48 Mbps -76
64 QAM 54 Mbps -75
n
BPSK MCS0_20 -90
QPSK MCS1_20 -89
QPSK MCS2_20 -87
16 QAM MCS3_20 -84
16 QAM MCS4_20 -81
64 QAM MCS5_20 -76
64 QAM MCS6_20 -75
64 QAM MCS7_20 -73
Table 14: Wi-Fi Rx Sensitivity 2.4 GHz
Wi-Fi 5 GHz / CH 36 Modulation Data Rates Sensitivity (dBm)
a
BPSK 6 Mbps -93
BPSK 9 Mbps -92
QPSK 12 Mbps -91
QPSK 18 Mbps -88
16 QAM 24 Mbps -85
16 QAM 36 Mbps -82
64 QAM 48 Mbps -77
64 QAM 54 Mbps -75
n
BPSK MCS0_20 -93
QPSK MCS1_20 -90
QPSK MCS2_20 -87
16 QAM MCS3_20 -84
16 QAM MCS4_20 -81
64 QAM MCS5_20 -76
64 QAM MCS6_20 -75
64 QAM MCS7_20 -73
Table 14: Wi-Fi Rx Sensitivity 5 GHz
BLE Tx Power
BLE transmits power with an RF Pad at 25 °C. To measure WE310G4-P power, remove
the antenna and connect a pigtail to the RF pad.
Packet Type CH 19 Output Power (dBm)
LE 1M 5
LE 2M 5
Table 14: BLE Tx Power
BLE Rx Sensitivity
BLE Rx sensitivity at RF pad @ 25 °C.
Packet Type CH 19 Rx Sensitivity (dBm)
LE 1M -97
LE 2M -94
Table 14: BLE Rx Sensitivity
