Tenda W330R User Manual

Wireless-N Broadband Router
is Dynamic IP, it means
your IP address keeps
changing every time you
connect. You do not need
to enter the information
like Mode 2 or Mode 3.
ÎConnection Mode 3:
Static IP
In this screen, fill the
network address
information from your ISP
in the IP Address, Subnet
Mask, Gateway and
Primary DNS server
fields and click “Next”.
ÎConnection Mode 4:
L2TP
Select L2TP(Layer 2
Tunneling Protocol) if
your ISP use a L2TP
connection, your ISP will
provide you with a
username and password
please fill in the
12

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
