Tenda W330R User Manual

Wireless-N Broadband Router
parameters.
L2TP provides two
access modes.
If the L2TP offered by
your ISP is Dynamic IP:
Please select Dynamic
IP .
If the L2TP offered by
your ISP is Static IP:
Please fill in the
parameters provided by
your ISP.
After configuration, please
click “Next”.
ÎConnection Mode 5:
PPTP
If the connection is “PPP
Tunneling Protocol”,
please input the following
parameters provided by
your ISP: Server IP
Address, User Name,
and Password.
13

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
