Tenda W330R User Manual

Wireless-N Broadband Router
PPTP provides two
access modes.
If the PPTP offered by
your ISP is Dynamic IP:
Please select Dynamic
IP.
If the PPTP offered by
your ISP is Static IP:
Please fill in the
parameters provided by
your ISP.
After configuration, please
click “Next”.
Click “Apply”, select
“Reboot” in System Tools
of the left menu and press
the “Reboot the router”
button.
It is rebooting now, please
wait for a few
minutes and DO NOT
power off it.
14

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
