13 MXC1347B
ROPE SPECIFICATIONS
WIRE ROPE:
14mm
35W x 7 NR 2070 MPa
MINIMUM BREAKING FORCE 165 kN
MACHINE SPLICE & THIMBLE EYE ONE END ONLY
LENGTH - 110m
RETRACT ROPE:
11mm
6 x 25 WRC G2070
MINIMUM BREAKING FORCE 82.4kN
EXTENSION CHAIN:
BL1066 LEAF CHAIN
MINIMUM BREAKING FORCE 40 000 KGF
TYRE SPECIFICATIONS
Type Condition Speed Load Rating
Pick & Carry
<1.44 km/h
10500 kg per tyre at
830 kPa (120 psi)
(dual fitment)
14.00 x 20
Dual Tyres
Highway
80 km/h
3050 kg per tyre at
620 kPa (90 psi)
(dual fitment)
TYRE INFLATION
Inflation Pressure
Type Position
Pick & Carry Highway Travel
Front
830 kPa (120 psi)
(Max RC 25 tonne)
830 kPa (120 psi)
14.00 x 20
Dual Tyres
Rear
620 kPa (90 psi) 620 kPa (90 psi)
