LMI DUTY
111
MAC25 LUG 1 LOAD CHART - 10 DEG. ART. MAC25 LUG 1 LOAD CHART - 40 DEG. ART.
COUNTERWEIGHT ON FRONT OF CRANE - SPRING LOCKOUTS ENGAGED COUNTERWEIGHT ON FRONT OF CRANE - SPRING LOCKOUTS ENGAGED
S.W.L IN KILOGRAMS FOR SLEW ANGLES OF 10 DEGREES OR LESS EITHER S.W.L IN KILOGRAMS FOR SLEW ANGLES OF GREATER THAN 10 DEGREES UP TO 40
SIDE OF STRAIGHT AHEAD (INDICATED BY GREEN LED ON DASH). DEGREES EITHER SIDE OF STRAIGHT AHEAD (INDICATED BY RED LED ON DASH).
BOOM ANGLE - UNDEFLECTED (REF.) BOOM ANGLE - UNDEFLECTED (REF.)
NOTE :
VALUES IN BRACKETS ( ) ARE ACTUAL RADIUS AT ZERO DEG. BOOM ANGLE.
NOTE :
VALUES IN BRACKETS ( ) ARE ACTUAL RADIUS AT ZERO DEG. BOOM ANGLE.
SWL IS AT THIS RADIUS SWL IS AT THIS RADIUS
LIFT & CARRY - THE S.W.L. SHALL BE CARRIED WITH THE MINIMUM BOOM LENGTH & AS CLOSE TO THE GROUND AS POSSIBLE AT SPEEDS NOT IN EXCESS OF 0.4 M/SEC (1.44 KM/HR)
NOTE : WEIGHT OF HOOKS, BLOCKS & OTHER LOAD HANDLING DEVICES SHALL BE ADDED TO THE WEIGHT OF THE LOAD
RADIUS
BOOM PIVOT TO LUG 1, 1st EXTENSION, THIRD EXTENSION RETRACTED
RADIUS
BOOM PIVOT TO LUG 1, 1st EXTENSION, THIRD EXTENSION RETRACTED
IN
(metres)
IN
(metres)
METRES
5.36 5.50 6.00 6.50 7.00 7.50 8.00 8.50 9.00 9.46
METRES
5.36 5.50 6.00 6.50 7.00 7.50 8.00 8.50 9.00 9.46
1.4
24350 24300 24100 23950 23750 23600 23450 23250 23100 22950
1.4
24350 24300 23450 21550 17850 16350 15100 14100 13200 12450
40 42 47 51 54 57 59 61 63 64 40 42 47 51 54 57 59 61 63 64
2
19500 19400 19100 18850 18600 18400 18200 18000 17900 17750
2
17450 17350 17000 16750 16500 15650 14700 13850 13100 11300
29 31 38 44 48 51 54 56 59 60 29 31 38 44 48 51 54 56 59 60
2.5
15250 15200 14950 14700 14500 14300 14150 14000 13850 13750
2.5
13600 13500 13250 13050 12800 12650 12500 12100 11400 10900
14 19 30 37 42 46 49 52 55 57 14 19 30 37 42 46 49 52 55 57
3
14200 13350 12100 11950 11750 11600 11450 11300 11200 11100
3
12650 11850 10750 10550 10350 10200 10050 9900 9800 9550
(2.7) (2.8) 18 29 35 41 45 48 51 53 (2.7) (2.8) 18 29 35 41 45 48 51 53
3.5
10800 9950 9800 9650 9500 9400 9300 9200
3.5
9500 8750 8600 8450 8300 8200 8100 8000
(3.3) 17 28 34 39 43 46 49 (3.3) 17 28 34 39 43 46 49
4
8900 8300 8150 8050 7950 7850 7750
4
7800 7250 7150 7000 6900 6800 6700
(3.8) 17 27 33 38 42 45 (3.8) 17 27 33 38 42 45
5
7500 6350 6000 5900 5800 5750
5
6500 5500 5150 5050 5000 4900
(4.3) (4.8) 16 25 31 36 (4.3) (4.8) 16 25 31 36
6
5400 4650 4450 4400
6
4650 3950 3750 3700
(5.3) (5.8) 15 23 (5.3) (5.8) 15 23
6.8
4000 3500
6.8
3350 2900
(6.3) (6.8) (6.3) (6.8)
S.W.L. ARE BASED ON 66.7% STABILITY & STRENGTH - S.W.L. ABOVE BOLD RED LINE ARE STRUCTURAL
S.W.L. ARE BASED ON FIRM, LEVEL GROUND (1% SLOPE (0.6 DEG) AS PER AS1418.5) WITH TYRES INFLATED AS PER NOTES
30/66 MXC1347B COUNTERWEIGHT - FRONT MAC 25 LUG 1 - 10 / 40 DEG
