Terex MAC 25 - Load Moment Indicator Duties

15 MXC1347B
LOAD MOMENT INDICATOR DUTIES
1500 kg COUNTERWEIGHT ON FRONT
DUTY DESCRIPTION
101 FALL BLOCK
102 RHINO HOOK
103 OFFSET HEAD – BOTTOM POSITION
104 OFFSET HEAD – TOP POSITION
105 3M FLYJIB –TOP POSITION - 0º OFFSET
106 3M FLYJIB –TOP POSITION – 12.5º OFFSET
107 4M FLYJIB – TOP POSITION - 5º OFFSET
108 4M FLYJIB – BOTTOM POSITION – 17.5º OFFSET
109 MAN BASKET
110 BUTT LUG
111 LUG 1 – BOOM 1
112 LUG 2 – BOOM 2
1500 kg COUNTERWEIGHT ON REAR
DUTY DESCRIPTION
201 FALL BLOCK
202 RHINO HOOK
203 OFFSET HEAD – BOTTOM POSITION
204 OFFSET HEAD – TOP POSITION
205 3M FLYJIB –TOP POSITION - 0º OFFSET
206 3M FLYJIB –TOP POSITION – 12.5º OFFSET
207 4M FLYJIB – TOP POSITION - 5º OFFSET
208 4M FLYJIB – BOTTOM POSITION – 17.5º OFFSET
209 MAN BASKET
210 BUTT LUG
211 LUG 1 – BOOM 1
212 LUG 2 – BOOM 2
1500+2160 kg COUNTERWEIGHT ON REAR
DUTY DESCRIPTION
301 FALL BLOCK
302 RHINO HOOK
303 OFFSET HEAD – BOTTOM POSITION
304 OFFSET HEAD – TOP POSITION
305 3M FLYJIB –TOP POSITION - 0º OFFSET
306 3M FLYJIB –TOP POSITION – 12.5º OFFSET
307 4M FLYJIB – TOP POSITION - 5º OFFSET
308 4M FLYJIB – BOTTOM POSITION – 17.5º OFFSET
309 MAN BASKET
310 BUTT LUG
311 LUG 1 – BOOM 1
312 LUG 2 – BOOM 2
