9. The winch rope is fully compensated for boom extension. The only
exception is when the third extension is being used. Refer to the operator’s
manual for information on the use of the third extension.
10. Do not allow the winch rope to unwind fully. Always ensure a minimum of
2 wraps of rope remain on the winch drum. Note the areas on the range
diagram where the fall block cannot reach the ground on 6 parts of rope.
11. Rated Capacity depends on tyre rating, tyre condition and tyre inflation
pressure. All tyres must be in good condition and must be inflated to the
recommended pressure before attempting a lift.
12. Pick & carry operation is permitted through the full Articulation range,
however, Rated Capacity is reduced above 10 Articulation. Use the
reduced capacities in the rated capacity chart if entering this Articulation
zone during the operation.
13. The maximum speed for pick & carry operation is 0.4m/s (1.44km/h). The
transfer case shall be set to low range.
14. Operation of this crane in excess of the Rated Capacity and disregard of the
instructions is hazardous.
7 MXC1347B
