Controls and Operating
10. Rear Brake Accumulator Pressure (Red)
Illuminates to warn of low pressure in the rear brake system accumulator. Stop the
machine if this light illuminates and do not operate until the fault is corrected.
11. Low Steering Pressure (Red)
Illuminates when the steering system oil pressure drops below 83 bar (1200 lbf/in²).
Stop the machine when this light illuminates and do not operate until the fault is
corrected.
12. Steering & Braking Tank Low Oil Level (Red)
Illuminates when the level in the tank falls below the safe operating level. Stop the
machine when this light illuminates and do not operate until the fault is corrected.
13. Parking Brake (Green)
Illuminates when the parking brake is applied.
14. Headlight Main Beam (Blue)
Illuminates when headlights are operated on main beam.
15. Direction Indicator (Green)
Flashes when the indicator lights are operating.
16. Body-up (Amber)
Illuminates to indicate that the body is NOT resting on the chassis. Never move the
machine until this light goes OUT.
17. Transmission Oil Temperature (Red)
Illuminates when the transmission oil temperature rises above the safe operating
temperature.
18. Brake Hydraulic Oil Temperature (Red)
Illuminates if brake cooling hydraulic oil overheats. Reduce speed and shift
transmission to the range that will maintain an engine speed as high as possible,
without exceeding the maximum recommendation, to increase oil circulation and
cooling. If the trouble persists, stop the machine and have the fault corrected.
19. Retarder Indicator (Amber)
Illuminates when the retarder is applied.
20. In-converter Indicator (Green)
Illuminates when the transmission is in Torque Converter drive. It goes OUT when
Lockup is engaged.
21. Check Trans (Red)
Illuminates to alert of a fault in the transmission shift system or abnormal
transmission temperature. The light will illuminate when the ignition keyswitch is
turned to position '1' to provide a bulb and system check and should go off a few
seconds after the engine is started.
22. Steering Filter Restriction (Amber)
Illuminates when the filter is restricted, indicating that a filter change is required.
23. Transmission Oil Filter Restriction (Amber)
Illuminates when the filter is restricted, indicating that a filter change is required.
Transmission will not upshift from first gear while this light is illuminated.
NOTE :
This lamp may illuminate at initial start up, due to the viscosity of
the oil when cold.
