Polarity display : For phase lag (LAG : current is slower than voltage) :
No symbol.
For lead phase (LEAD : current is faster than voltage) : “-”
 Power Factor measurement (COS
ψ
) :
Range
Resolution
Calculated Accuracy
0 ~ +1
0.001

3dgt

Measurement method : Calculate from apparent power S and active power P,
PF = COS
ψ
=
P S/

Display item : Power factor of each channel and its sum of multiple channels.
 Phase angle measurement (
ψ
) :
Range
Resolution
Calculated Accuracy
+90
°
~ 0
°
~ -90
°
0.1
°

3dgt

Measurement method : Calculate from power factor COS
ψ
,
ψ
= COS
-1
PF
.

Display item : Phase angle of each channel and its sum of multiple channels.

Polarity display : For phase lag (LAG : current is slower than voltage) :
No symbol.
For phase lead (LEAD : current is faster than voltage) : “-”.
 Frequency measurement (Hz) :
Range
Resolution
Accuracy
Measurement source
60HZ
0.1Hz

0.1%rdg

2dgt
Voltage U1 > 50V

Measurable input range : > 50V
 Three Phase Sequence Detection :
Input voltage range
Normal phase indication
Reverse phase indication
Measurement source
3P > 50V
U1, U2 and U3
 Active Power Energy measurement (KWh) :
Range
Resolution
Active power
accuracy
Timer interval
Timer Accuracy
3.999KWh
0.001KWh

1.0%rdg

20dgt
1 sec
±50ppm (25
℃
, 77
℉
)
39.99KWh
0.01KWh
399.9KWh
0.1KWh
3.999MWh
0.001MWh
39.99MWh
0.01MWh
119.3MWh
0.1MWh

Measurement display : Display all active power consumption energy (sum of
absolute values).
 Apparent Power Energy measurement (KVAh) :
