3-2 Safety Specifications
Category Rating : 1000V Measurement Category III, Pollution Degree 2.
: IEC 61010-1 2nd Edition
CAT III : Measurement category in which measurements performed in the
building installation.
Safety Characteristics :
Current Clamps, Model TES AC3600, to be used only with the Three-Phase
Power Analyzer, Model TES-3600.
This manual contains information and warning that must be followed by the user
to ensure safe operation and to keep the meter and its accessories in a safe
condition.
Use of this meter and its accessories in a manner not specified by the
manufacturer may impair the protection provided by the equipment.
Equipment operation, the responsible body shall be made aware that, if the
equipment is used in a manner not specified by the manufacturer, the protection
provided by the probe assembly may be impaired.
3-3 General Specification
Maximum voltage between voltage input terminals and earth ground :
1000 Vrms
Maximum rated working voltage for current input : 0.35 Vrms
Maximum current for current probe : 1000 Arms
Numerical 10 display : 10 display 4 digit LCD maximum reading 9999.
Battery life : approx. 50 hours.
Auto power off : approx. 30 minutes.
Low battery indication : The
is displayed when the battery voltage drops
below the operating voltage.
Backlight display time : Auto off approx. 30 seconds.
Sampling rate : Approx. 1 time per 2 seconds (Digital display).
Waveform and harmonic analyzer : 64 samples per period.
Current probe jaw opening diameter : Cables ψ40mm.
Operating temperature : 0℃ to 40℃
Operating humidity : Maximum relative humidity of 80% for temperatures up to
31℃ decrease linearly to 50% relative humidity at
40℃ (non-condensed).
Temperature coefficient : 0.1 (specified accuracy)/℃ (<18 or >28℃)
