TES TES-3600 - Single-Phase 2-Wire Measurement

17
Warning
To avoid shock or personal injury, keep fingers behind the tactile barrier, see
Figure 1.
Load Direction Arrow
Alignment Marks
Tactile Barrier
Figure 1
5-2 Single-Phase 2-Wire (1P2W) Power System Measurement
Application :
Receptacle branch circuit
Lighting loads
 Troubleshooting electrical distribution system.
 Measuring current harmonic (use PC).
 Measuring line rms voltage.
 Measuring power on single phase loads.
 Measuring line rms current.
 Measuring frequency.
 Measuring voltage harmonics (use PC).
 Measuring current harmonics (use PC).
 Measuring voltage waveform (use PC).
 Measuring current waveform (use PC)
 Measuring the load on a transformer.
 Recording the load on a transformer.
