: Low battery indication.
ψ: Phase angle display.
: Phase angle unit.
1P2W : Measure signal-phase two-wire power line indication.
1P3W : Measure signal-phase three-wire power line indication.
3P3W2M : Measure three-phase three-wire power line indication.
3P4W : Measure three-phase four-wire power line indication.
P1 : Phase 1 active power measured display indication.
P2 : Phase 2 active power measured display indication.
P3 : Phase 3 active power measured display indication.
Pt : Total active power measured display indication and total active energy
measured display indication.
KW : Active power unit.
KWh, MWh : Active energy unit.
PF1 : Phase 1 power factor measured display.
PF2 : Phase 2 power factor measured display.
PF3 : Phase 3 power factor measured display.
PFt : Total power factor measured display.
I4 : Current probe 4 current measured display.
Hz : Frequency unit.
DATA No. : Last manual datalogged memory address number indication
(01~99).
M : Manual datalogged indication, M displays one time store one sets data into
the memory.
DATA R No. : Recall manual datalogged address number indication, the
memory data displayed for read.
DATA M : Auto datalogging indication, M disappears one time store one sets
data into the memory .
01 ~ 10 : Maximum 10 memory blocks can be use, only 12,000
sets data can be stored in one block.
Maximum 20,000 sets data can be stored.
FF : Memory full indication, if exceed 10 memory blocks or
exceed 20,000 stored data.
Q1 : Phase 1 reactive power measured display indication.
Q2 : Phase 2 reactive power measured display indication.
