1. Press
key to turn on the meter.
2. Press WIRING key to select the 3P3W2M electrical system under test, the
3P3W2M annunciator will be displayed.
3. Connect the voltage test leads and current probe to the meter.
Connect the black voltage test lead to the “N” terminal.
Connect the red voltage test lead to the “U1” terminal.
Connect the yellow voltage test lead to the “U2” terminal.
Connect the I1 current probe output plug to the “I1” jack.
Connect the I2 current probe output plug to the “I2” jack.
4. Connect the voltage test leads and current probe to the electrical equipment to be
tested.
CAUTION
If possible, before connecting the voltage test leads and current probe to
the electrical equipment to be tested, take off the electrical equipment’s
power.
Connect the black voltage test alligator to the line “B”.
Connect the red voltage test alligator to the line “A”.
Connect the yellow voltage test alligator to the line “C”.
Press I1 current probe trigger to open the jaw and fully enclose the Line “A”.
Press I2 current probe trigger to open the jaw and fully enclose the Line “C”.
5. Press POWER key to select (P1, Q1, S1, PF1), (P2, Q2, S2, PF2) and (Pt,
Qt, St, PFt) measured values.
6. Frequency (Hz), Phase Angle (Θ) and Power Factor (pF) measurement:
Hz : Press “Hz” key, PF1 will show “Hz”. Press “PF” key to exit.
Θ : Press “Θ” key, PF1 will show “ψ”. Press “PF” key to exit.
pF : Press “PF” key.
