27
4. Connect the voltage test leads and current probe to the electrical equipment to be
tested.
CAUTION
 If possible, before connecting the voltage test leads and current probe to
the electrical equipment to be tested, take off the electrical equipment’s
power.
 Connect the black voltage test alligator to the neutral line “N”.
 Connect the red voltage test alligator to the line “A”.
11
Connect the yellow voltage test alligator to the line “B”.
12
Connect the blue voltage test alligator to the line “C”.
13
Press I1 current probe trigger to open the jaw and fully enclose the Line “A”.
14
Press I2 current probe trigger to open the jaw and fully enclose the Line “B”.
15
Press I3 current probe trigger to open the jaw and fully enclose the Line “C”.
16
Press I4 current probe trigger to open the jaw and fully enclose neutral line “N”.
5. Press POWER key to select (P1, Q1, S1, PF1), (P2, Q2, S2, PF2), (P3, Q3,
S3, PF3) and (Pt, Qt, St, PFt) measured values.
6. Frequency (Hz), Phase Angle (Θ), Neutral Line Current (I4) and Power Factor
(pF) measurement :
 Hz : Press “Hz” key, PF1 will show “Hz”. Press “PF” key to exit.
 Θ: Press “Θ” key, PF1 will show “ψ”. Press “PF” key to exit.
 I4 : Press “I4” key, PF1 will show “I4”. Press “PF” key to exit.
 pF : Press “PF” key.
