Tevo Tarantula Pro - Hotbed Assembly

17 18
Install the hotbed and tighten the nuts just some turns as these are
later used to adjust the bed level. These parts can be found from bag
B-02-1.
Slide the front panel in extrusions and tighten the M5 bolts in both
sides of the front panel.
*
Hotbed assembly
Controller, PSU and front panel installation
2 x M5x8 lowprofile
4 x M4x40 countersunk
4 x bed spring
4 x thumb nut
3 x M5x8 lowprofile
3 x T-nut
