Circuit Module Physical Construction
Table 4. bq76930EVM Circuit Module Bill of Materials (continued)
Designator Qty Value Description Package Reference Part Number MFR Alt. Part Number Alt. MFR
Q6, Q7, Q8, Q9, Q10 5 20V MOSFET, P-CH, 20V, 0.83A, FDY1002PZ Fairchild Semiconductor None
Q14, Q22 2 100V MOSFET, N-CH, 100V, 0.19A, SOT-23 SOT-23 BST82,215 NXP Semiconductor None
Q16, Q17 2 100V MOSFET, N-CH, 100V, 0.17A, SOT-23 SOT-23 BSS123 Fairchild Semiconductor None
Q18 1 0.5V Transistor, PNP, 300V, 0.2A, SOT-23 SOT-23 MMBTA92 Fairchild Semiconductor None None
Q19 1 50V MOSFET, N-CH, 50V, 0.22A, SOT-23 SOT-23 BSS138 Fairchild Semiconductor None
Q20 1 0.21V Transistor, NPN, 20V, 5.25A, SOT-89 SOT-89 ZXTN19100CZTA Diodes Inc.
R2, R4, R44, R45, R46, R47, 17 100 RES, 100 ohm, 1%, 0.125W, 0805 0805 CRCW0805100RFKEA Vishay-Dale
R61, R62, R79, R82, R83, R89,
R90, R114, R115, R118, R119
R3 1 0.001 RES, 0.001 ohm, 1%, 2W, 4527 4527 WSR21L000FEA Vishay-Dale
R5, R8, R9, R104, R111, R116, 7 1.00Meg RES, 1.00Meg ohm, 1%, 0.125W, 0805 0805 CRCW08051M00FKEA Vishay-Dale
R117
R6, R87, R123 3 0 RES, 0 ohm, 5%, 0.125W, 0805 0805 CRCW08050000Z0EA Vishay-Dale
R7, R20, R21, R22, R23, R24, 15 1.00k RES, 1.00k ohm, 1%, 0.125W, 0805 0805 CRCW08051K00FKEA Vishay-Dale
R25, R26, R27, R28, R29, R30,
R31, R58, R59
R10, R11, R12, R13, R14, R15, 10 100 RES, 100 ohm, 1%, 0.25W, 1206 1206 CRCW1206100RFKEA Vishay-Dale
R16, R17, R18, R19
R32, R33, R34, R35, R36, R37, 14 10.0k RES, 10.0k ohm, 1%, 0.125W, 0805 0805 CRCW080510K0FKEA Vishay-Dale
R38, R39, R40, R41, R48, R49,
R108, R112
R42 1 499k RES, 499k ohm, 1%, 0.125W, 0805 0805 CRCW0805499KFKEA Vishay-Dale
R43 1 3.01k RES, 3.01k ohm, 1%, 0.125W, 0805 0805 CRCW08053K01FKEA Vishay-Dale
R75, R78, R101, R103, R107, 6 100k RES, 100k ohm, 1%, 0.125W, 0805 0805 CRCW0805100KFKEA Vishay-Dale
R109
R77, R129, R130, R131, R132, 11 200 RES, 200 ohm, 1%, 0.125W, 0805 0805 CRCW0805200RFKEA Vishay-Dale
R133, R134, R135, R136, R137,
R138
R86 1 0 RES, 0 ohm, 5%, 0.25W, 1206 1206 CRCW12060000Z0EA Vishay-Dale
R94 1 300k RES, 300k ohm, 0.1%, 0.1W, 0603 0603 RG1608P-304-B-T5 Susumu Co Ltd
R95, R97 2 100k RES, 100k ohm, 0.1%, 0.1W, 0603 0603 RG1608P-104-B-T5 Susumu Co Ltd
R96, R102 2 11.3k RES, 11.3k ohm, 0.1%, 0.1W, 0603 0603 RG1608P-1132-B-T5 Susumu Co Ltd
R105 1 5.6k RES, 5.6k ohm, 5%, 1W, 2512 2512 ERJ-1TYJ562U Panasonic
R106 1 196k RES, 196k ohm, 1%, 0.125W, 0805 0805 CRCW0805196KFKEA Vishay-Dale
R110, R122 2 49.9k RES, 49.9k ohm, 1%, 0.125W, 0805 0805 CRCW080549K9FKEA Vishay-Dale
R120 1 221k RES, 221k ohm, 1%, 0.125W, 0805 0805 CRCW0805221KFKEA Vishay-Dale
R121 1 698 RES, 698 ohm, 1%, 0.125W, 0805 0805 CRCW0805698RFKEA Vishay-Dale
RT1, RT2 2 10.0k ohm Thermistor NTC, 10.0k ohm, 1%, Disc, 5x8.4 mm Disc, 5x8.4 mm 103AT-2 SEMITEC Corporation
S1, S2 2 Switch, Tactile, SPST-NO, 0.05A, 12V, SMT SW, SPST 6x6 mm 4-1437565-1 TE Connectivity
S3 1 Switch, SPST 9Pos, Rocker, TH 9.65X8X24.9mm 76SB09ST Grayhill
S4 1 Switch, SPST 8Pos, Rocker, TH 9.65X8X22.4mm 76SB08ST Grayhill
SH-J6, SH-J7, SH-J11, SH-J12, 10 1x2 Shunt, 100mil, Gold plated, Black Shunt 969102-0000-DA 3M SNT-100-BK-G Samtec
SH-J14-3, SH-J14-5, SH-J14-7,
SH-J14-9, SH-J15-5, SH-J16-3
TP3, TP4, TP5, TP6 4 Black Test Point, TH, Multipurpose, Black Keystone5011 5011 Keystone
41
