Texas Instruments bq76930 - Bq76940 Evm Circuit Module Bill of Materials

www.ti.com Circuit Module Physical Construction
7.3.2 bq76940EVM Bill of Materials
The bill of materials for the bq76940EVM circuit module is shown in Table 5.
Table 5. bq76940EVM Circuit Module Bill of Materials
Designator Qty Value Description Package Reference Part Number MFR Alt. Part Number Alt. MFR
!PCB1 1 Printed Circuit Board PWR524 Any - -
C1, C2, C3, C40, C41, C42 6 0.1uF CAP, CERM, 0.1uF, 50V, +10/%, X7R, 0603 0603 GCM188R71H104KA57B MuRata
C4, C5, C6, C7 4 0.1uF CAP, CERM, 0.1uF, 100V, +/-10%, X7R, 0603 0603 GRM188R72A104KA35D MuRata
C8, C9, C10, C11, C12, C13, C14, C15, 21 1uF CAP, CERM, 1uF, 16V, +10/%, X7R, 0805 0805 GRM21BR71C105KA01L MuRata
C16, C17, C18, C19, C21, C22, C23, C28,
C29, C30, C31, C32, C33
C24, C25, C26 3 4700pF CAP, CERM, 4700pF, 50V, +/-10%, X7R, 0805 0805 08055C472KAT2A AVX
C27 1 4.7uF CAP, CERM, 4.7uF, 10V, +10/%, X7R, 0805 0805 GRM21BR71A475KA73L MuRata
C34, C35, C36 3 10uF CAP, CERM, 10uF, 35V, +/-10%, X7R, 1210 1210 GRM32ER7YA106KA12L MuRata
C37 1 1uF CAP, CERM, 1uF, 50V, +/-10%, X7R, 1206 1206 GRM31MR71H105KA88L MuRata
C39 1 3300pF CAP, CERM, 3300pF, 25V, +/-10%, X7R, 0603 0603 GRM188R71E332KA01D MuRata
D1 1 75V Diode, TVS, Uni, 75V, 1500W, SMC SMC SMCJ75A Fairchild
Semiconductor
D2, D22, D23, D24, D41, D46 6 100V Diode, Ultrafast, 100V, 0.15A, SOD-123 SOD-123 1N4148W-7-F Diodes Inc.
D3, D45, D47 3 16V Diode, Zener, 16V, 500mW, SOD-123 SOD-123 MMSZ5246B-7-F Diodes Inc.
D4 1 600V Diode, Ultrafast, 600V, 3A, SMC SMC MURS360T3G ON Semiconductor
D6, D7, D8, D9, D10, D11, D12, D13, D14, 21 5.6V Diode, Zener, 5.6V, 200mW, SOD-323 SOD-323 MMSZ5232BS-7-F Diodes Inc.
D15, D25, D26, D27, D28, D29, D30, D31,
D43, D44, D53, D54
D48, D49, D50, D51, D52 5 Green LED, Green, SMD 1.6x0.8x0.8mm LTST-C190GKT Lite-On
D55 1 Orange LED, Orange, SMD 1.6x0.8x0.8mm LTST-C190KFKT Lite-On
D56 1 6.8V Diode, Zener, 6.8V, 500mW, SOD-123 SOD-123 MMSZ5235B-7-F Diodes Inc.
FID1, FID2, FID3 3 Fiducial mark. There is nothing to buy or mount. Fiducial N/A N/A
H1, H2, H3, H4 4 Bumpon, Hemisphere, 0.375 X 0.235, Black Black Bumpon SJ61A2 3M
J1, J2, J3, J4 4 TERMINAL SCREW PC 30AMP, TH 12.9x6.3x7.9 mm 8199 Keystone
J5 1 Header, 3.5mm, 11POS, R/A, TH 39.90x7.03x9.33 mm 395021011 Molex
J6, J7, J11, J12 4 Header, 100mil, 2x1, Tin plated, TH Header, 2 PIN, 100mil, Tin PEC02SAAN Sullins Connector
Solutions
J8, J17 2 Header, 100mil, 4x1, R/A, TH 4x1 R/A Header 22-05-3041 Molex
J9 1 Header, 3.5mm, 5POS, R/A, TH 19.03x7.03x9.33 mm 395021005 Molex
J14 1 Header, 100mil, 5x2, Tin plated, TH Header, 5x2, 100mil, Tin PEC05DAAN Sullins Connector
Solutions
J15 1 Header, 100mil, 3x2, Tin, TH 3x2 Header PEC03DAAN Sullins Connector
Solutions
J16 1 Header, 100mil, 3x1, Tin plated, TH Header, 3 PIN, 100mil, Tin PEC03SAAN Sullins Connector
Solutions
LBL1 1 Thermal Transfer Printable Labels, 0.650" W x 0.200" H - PCB Label 0.650"H x 0.200" W THT-14-423-10 Brady - -
10,000 per roll
P1 1 CONN TERM BLOCK 3.5MM 11POS R/A Term Block Plug 39500-0011 Molex Connector 1840450 Phoenix
Corporation Contact
51
