Circuit Module Physical Construction www.ti.com
Table 5. bq76940EVM Circuit Module Bill of Materials (continued)
Designator Qty Value Description Package Reference Part Number MFR Alt. Part Number Alt. MFR
P2 1 CONN TERM BLOCK 3.5MM 5POS R/A Term Block Plug 39500-0005 Molex Connector - -
Corporation
Q2, Q4 2 100V MOSFET, N-CH, 100V, 18A, DDPAK DDPAK AOB290L AOS None
Q5, Q15 2 -100V MOSFET, P-CH, -100V, -0.6A, SOT-23 SOT-23 ZXMP10A13FTA Diodes Inc. None
Q6, Q7, Q8, Q9, Q10, Q11, Q12, Q13 8 20V MOSFET, P-CH, 20V, 0.83A, FDY1002PZ Fairchild None
Semiconductor
Q14, Q22 2 100V MOSFET, N-CH, 100V, 0.19A, SOT-23 SOT-23 BST82,215 NXP Semiconductor None
Q16, Q17 2 100V MOSFET, N-CH, 100V, 0.17A, SOT-23 SOT-23 BSS123 Fairchild None
Semiconductor
Q18 1 0.5V Transistor, PNP, 300V, 0.2A, SOT-23 SOT-23 MMBTA92 Fairchild None None
Semiconductor
Q19 1 50V MOSFET, N-CH, 50V, 0.22A, SOT-23 SOT-23 BSS138 Fairchild None
Semiconductor
Q20 1 0.21V Transistor, NPN, 20V, 5.25A, SOT-89 SOT-89 ZXTN19100CZTA Diodes Inc.
R2, R4, R44, R45, R46, R47, R60, R61, 18 100 RES, 100 ohm, 1%, 0.125W, 0805 0805 CRCW0805100RFKEA Vishay-Dale
R62, R79, R82, R83, R89, R90, R114,
R115, R118, R119
R3 1 0.001 RES, 0.001 ohm, 1%, 2W, 4527 4527 WSR21L000FEA Vishay-Dale
R5, R8, R9, R104, R111, R116, R117 7 1.00Meg RES, 1.00Meg ohm, 1%, 0.125W, 0805 0805 CRCW08051M00FKEA Vishay-Dale
R6, R87 2 0 RES, 0 ohm, 5%, 0.125W, 0805 0805 CRCW08050000Z0EA Vishay-Dale
R7, R20, R21, R22, R23, R24, R25, R26, 22 1.00k RES, 1.00k ohm, 1%, 0.125W, 0805 0805 CRCW08051K00FKEA Vishay-Dale
R27, R28, R29, R30, R31, R57, R58, R59,
R63, R64, R65, R66, R67, R68
R10, R11, R12, R13, R14, R15, R16, R17, 15 100 RES, 100 ohm, 1%, 0.25W, 1206 1206 CRCW1206100RFKEA Vishay-Dale
R18, R19, R52, R53, R54, R55, R56
R32, R33, R34, R35, R36, R37, R38, R39, 19 10.0k RES, 10.0k ohm, 1%, 0.125W, 0805 0805 CRCW080510K0FKEA Vishay-Dale
R40, R41, R48, R49, R69, R70, R71, R72,
R73, R108, R112
R42 1 499k RES, 499k ohm, 1%, 0.125W, 0805 0805 CRCW0805499KFKEA Vishay-Dale
R43 1 3.01k RES, 3.01k ohm, 1%, 0.125W, 0805 0805 CRCW08053K01FKEA Vishay-Dale
R75, R78, R101, R103, R107, R109 6 100k RES, 100k ohm, 1%, 0.125W, 0805 0805 CRCW0805100KFKEA Vishay-Dale
R76, R124, R125, R126, R127, R128, 16 200 RES, 200 ohm, 1%, 0.125W, 0805 0805 CRCW0805200RFKEA Vishay-Dale
R129, R130, R131, R132, R133, R134,
R135, R136, R137, R138
R85 1 0 RES, 0 ohm, 5%, 0.25W, 1206 1206 CRCW12060000Z0EA Vishay-Dale
R94 1 300k RES, 300k ohm, 0.1%, 0.1W, 0603 0603 RG1608P-304-B-T5 Susumu Co Ltd
R95, R97 2 100k RES, 100k ohm, 0.1%, 0.1W, 0603 0603 RG1608P-104-B-T5 Susumu Co Ltd
R96, R102 2 7.68k RES, 7.68k ohm, 0.1%, 0.1W, 0603 0603 RG1608P-7681-B-T5 Susumu Co Ltd
R105 1 5.6k RES, 5.6k ohm, 5%, 1W, 2512 2512 ERJ-1TYJ562U Panasonic
R106 1 196k RES, 196k ohm, 1%, 0.125W, 0805 0805 CRCW0805196KFKEA Vishay-Dale
R110, R122 2 49.9k RES, 49.9k ohm, 1%, 0.125W, 0805 0805 CRCW080549K9FKEA Vishay-Dale
R120 1 221k RES, 221k ohm, 1%, 0.125W, 0805 0805 CRCW0805221KFKEA Vishay-Dale
R121 1 698 RES, 698 ohm, 1%, 0.125W, 0805 0805 CRCW0805698RFKEA Vishay-Dale
RT1, RT2, RT3 3 10.0k Thermistor NTC, 10.0k ohm, 1%, Disc, 5x8.4 mm Disc, 5x8.4 mm 103AT-2 SEMITEC
ohm Corporation
